Small Winder for SWG

Item No:ZD-M200

Description:It is a desktop winding machine, which can produce spiral wound gasket with inner ring or without inner ring. Driven by variable frequency gear motor, with special tool to take off molds of gaskets without inner ring easily, no need to uninstall molds.

Options: 1. V or W profile, thk 3.2mm 4.5mm 6.4mm 7.2mm

2. Molds of customized size are available on request.

Technical Parameter:

Gasket Size	1/2”-6” with inner ring / without inner ring
Nominal Thickness	4.5mm
Maximum Outer Diameter	200mm
Minimum Inner Diameter	15mm
Repeatability of Outer Diameter	±0.5mm
Rotational Speed	0 – 240 rpm
Total Power	2.2 KW
Motor Power	0.75 KW
Voltage	380V/220V
Air Pressure	6-8 BAR
Variable Frequency Controller	2.2G
Dimension	12008501650mm
Weight	280 KG
